Automatic Vacuum Infilling Nitrogen Tin Can Seaming Machine
This machine is suitable for sealing all kinds of round specification ring-pull can of tinplate can, plastic bottle, aluminum alloy can and paper cans. It adopts vacuum pump for sealing vacuum chamber, can obtain a high degree of vacuum. Widely used in canned food, beverages, spices, health products, etc.
Features
1. Seaming rollers are made of 440C stainless steel with high hardness and not easy to be rusty with good sealing effect.
2. It has two working modes, vacuum nitrogen filling sealing or vacuum sealing.
3. In the case of vacuum and nitrogen filling, the residual oxygen content can reach below 3%.
4. The cans will not rotate during the sealing process, only the sealing rollers rotate to complete the sealing, reliable and safe, especially suitable for fragile material and liquid packaging.
5. All electrical appliances and pneumatic components are manufactured by well-known manufacturers at home and abroad, reliable and stable quality.
6. It can be directly connected with filling machine, labeling machine and so on to constitute the packaging line.
|
|
220V/50Hz 110V/60HZ |
| Power |
3KW(Include vacuum pump) |
| Application of can height |
70-250mm (can be customized) |
| Application of can diameter |
60-150mm (can be customized) |
| Maximum vacuum |
0.08mpa |
| Gas consumption |
0.6M3/0.7Mpa |
| Speed |
6-8 cans/min(can be customized) |
| Dimention(L*W*H) |
2000×900×18500mm |
| Net weight |
550kg |
