The vacuum capping machine is suitable for the sealing of the glass bottle of various shapes and specifications, the bottle and the cover are automatically delivered to the vacuum chamber position, then the vacuum chamber is formed, the vacuum is vacuumed, and the cover is tightened.
Operating procedures:
The bottle is taken from the conveyor belt to the station, and then automatically capped and pre-selected by the automatic capper. Finally, the final vacuum cap is carried out by a vacuum capping station. Filling, labeling, sealing and other functions can be choosed according to customer requirements.
| Machine model |
|
|
| Suitable bottle diameter | 45-85mm(can be customized) | |
| Suitable cap diameter | 35-75mm(can be customized) | |
| Capping speed | 15-25 BPM(it depends on product size) | |
| Suitable bottle | Round or square shaped bottle barrel bucket | |
| Characteristic | Vacuum capping | |
| Power specifications | 380v/220V 50/60hz 2.5kw | |
| Machine weight | 380kg | |
| Outline dimension | 2000×1100×2100 mm |
、
| 1pcs/ctn |
